Vertical Compound Crusher

PFL compound crusher is kind of vertical shaft sand making machine. It is adjustable fine crushing equipment without screen bar and suitable for crushing brittle materials with medium hardness and low water content.

< 220mmFeed Size
22-355KWMotor Power
10-85 t/hProcessing capacity

Get Quotes Leave Message

60S Quick response
30 min Technical reply
24h design proposal
Email:sales@zchmachinery.com

What is Vertical Compound Crusher?

PFL Compound crusher is also called vertical crusher because of its vertical shaft with up and down placement structure design. It could be used for fine crusher and coarse grinding process and it is one of the general equipment in sand production line and gravel production plant. Compound crusher is widely used in all kinds of ore, cement, gypsum, limestone, dolomite, quartz stone, coal gangue, refractory materials, bauxite clinker, emery, glass raw materials such as high hard and special hard material crushing. At present, it is a better model to replace cone crusher, roller crusher and ball mill in the world.

How to choose Vertical Compound Crusher?

The composite crushing hammer and rotor are rigidly connected, and the inertia of the whole rotor is used to impact material, which can obtain greater speed and kinetic energy, making it easier to crush and lower energy consumption.

The structure of the crushing cavity is designed to be large, so that the material has a certain space for movement in it. The material is impacted and can be fully broken after repeated blows.

The impact crushing steel disc structure and the hammer disc are staggered. This kind of new design enhances the working performance of the crusher effectively .

The combined structure of hammer head make it easy to replace severely worn parts only. It greatly improves the service life of the hammer head, and effectively reduces the production cost and the replacement frequency of the wearing parts of the equipment.

Get Price List

High Quality

Large crushing ratio, discharging particle size can be adjusted arbitrarily, not affected by wear of hammer and liner plate.
Customized Design

Without screen bar, it is not easy to block when crushing materials with high moisture content and mud content.
Good Performance

The unbreakable material can be discharged automatically due to elastic adjustment mechanism and crusher machine will not be damaged.

Product features

Good sealing and dust removal device eliminate dust pollution to meet environmental standards.

Working principle

Materials drop into high speed rotating impeller in vertical, under high speed centrifugal force, stroked and crushed with materials scattered around the impeller in umbrella, after repeatedly impacting then there will be forming eddy current between the impeller and frame, materials will be crushed again and finally discharge from outlet directly, whole system formed closed circuit, separated by outer screen to control fineness.

Specification

Model	Feeding Size(mm)	Output Size(mm)	Capacity (t/h)	Power(kw)	Overall Dimension (LWH)
PFL-800	< 50	< 3-5	10-20	22-37	210012001700
PFL-1000	< 80		20-40	45-75	260014001900
PFL-1250	< 150		40-70	75-132	280016002100
PFL-1500	< 180		70-100	132-200	310019002200
PFL-1750	< 200		130-190	200-315	371023602390
PFL-2000	< 220		200-260	315-355	410026602620
